608032B | 608032C | 608032D | 608032E | 608032F | |
---|---|---|---|---|---|
System specifications | |||||
Size | A (26.9 mm) | B (33.7 mm) | C (42.4 mm) | D (48.3 mm) | E (60.3 mm) |
Type | Clamp-on tee | Clamp-on tee | Clamp-on tee | Clamp-on tee | Clamp-on tee |
Color | Silver | Silver | Silver | Silver | Silver |
Specifications tubefittings | |||||
Size | B | C | D | E | F |
Weight (kg) | 0.27 | 0.32 | 0.5 | 0.55 | 0.91 |
Outer diameter (") | ¾ | 1 | 1¼ | 1½ | 2 |
Amount in box | 60 | 60 | 20 | 20 | 10 |
Masterbox specifications | |||||
Width (cm) | 24 | 24 | 24 | 24 | 24 |
Height (cm) | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 |
Depth (cm) | 28.5 | 28.5 | 28.5 | 28.5 | 28.5 |
General additional specifications | |||||
Measurements screw | 1/4" x 12,5 mm | 1/4" x 12,5 mm | 3/8” x 12,7 mm | 3/8” x 12,7 mm | 3/8” x 12,7 mm |
