608010TA | 608010TB | 608010TC | 608010TD | |
---|---|---|---|---|
System specifications | ||||
Size | T (21.3 mm) | A (26.9 mm) | B (33.7 mm) | C (42.4 mm) |
Type | Flange. round | Flange. round | Flange. round | Flange. round |
Color | Silver | Silver | Silver | Silver |
Specifications tubefittings | ||||
Size | A | B | C | D |
Weight (kg) | 0.21 | 0.29 | 0.45 | 0.4867 |
Outer diameter (") | ½ | ¾ | 1 | - |
Amount in box | 100 | 70 | 40 | 25 |
Masterbox specifications | ||||
Width (cm) | 24 | 24 | 24 | 24 |
Height (cm) | 22.5 | 22.5 | 22.5 | 22.5 |
Depth (cm) | 28.5 | 28.5 | 28.5 | 28.5 |
General additional specifications | ||||
Measurements screw | 1/8” x 10 mm | 1/4" x 12,5 mm | 1/4" x 12,5 mm | 1/4" x 12,5 mm |
